Advantages
Structure: Heavy duty
Spindle: 3kw water cooled
Machine frame: Thick steel
Control system: DSP A11
Driving motor: Brushless microstepper motors
XYZ axis Taiwan Hiwin square rail
XY axis Helical rack and pinion
Z axis TBI ballscrew
Inverter: Best Brand
Table: Aluminum T-slot table
Lubrication System
Tool sensor
Machine working voltage: 220V/380V
| Model | True CNC -1325 | Custom Size |
| Working Size | 1300x2500x200mm | 1500x3000mm 2000x3000mm 2000x4000mm Other Size |
| CNC Router Table Size | 1450*2950mm | |
| Accuracy | +0.03mm | |
| CNC Router Table Surface | Aluminium T-slot Table | |
| Frame | Heavy & Thick Steel Square Structure | |
| X-Y Structure | Gear and rack Transmission | |
| Z Structure | Ball Screw of TBI, Taiwan | |
| Rapid Feed Rate | 25000mm/min | |
| Maximum Speed Rate | 20000mm/min | |
| Spindle Power | 3kw | |
| Spindle Speed | 0-18000RPM for Water Cooled | |
| Collet System | Highly Precise CNC ER 25 Collet (optional) | |
| Drive Motors | Stepper motor and drivers | |
| Working Voltage | Single phase 220v 50Hz | |
| Parameters | Standard Specifications ABP-1325-PZ | |
| Operating System | DSP A11 | |
| Computer Interface | USB | |
| Running Environment | Temperature: 0°C~45°C, Relative Humidity: 30%~75% | |
| Machine Power | 5kw | |
| Machine Dimension | 2150*3000*1800mm | |
| Packing Size | 2250*3200*2100mm | |
✅ Installation & Setup Support
Our trained technicians will assist you with onsite installation and training for smooth operations.
✅ Remote Troubleshooting
Dedicated customer support via phone, video call, and remote desktop sessions for quick resolution.
✅ Spare Parts & Consumables
Ready availability of original spare parts, printheads, and UV inks to ensure uninterrupted operations.
✅ Annual Maintenance Contracts (AMC)
Optional AMCs are available to keep your machine running at peak performance with regular checkups.
Q1. What types of materials can be printed on?
A: You can print on various rigid materials like glass, ceramic, wood, MDF, acrylic, metal, PVC, sunboard, and more.
Q2. Does it support white and varnish printing?
A: Yes, the printer supports CMYK+W (White) and CMYK+WV (White + Varnish) configurations.
Q3. What is the maintenance requirement?
A: Regular head cleaning and system checkups are recommended. We provide detailed guidance and support.
Q4. Can I print on dark surfaces?
A: Absolutely! With white ink support, you can easily print on dark or colored surfaces.
Q5. Is training provided?
A: Yes, complete training is provided during installation including software usage and media handling.
Q6. What is the lifespan of the printhead?
A: With proper maintenance,Printheads last for a long time.
Q7. What is the drying time for the prints?
A: The UV lamps provide instant drying, enabling immediate handling or post-processing.
