DTF Transfer Process
Printing colorful picture on the film
Shaking of white adhesive powder
Baking the powder to melted state
Heating and press for 8-15 sec
Peeling off the sheet
Print image transfer on the product
DTF Transfer Process
Printing colorful picture on the film
Shaking of white adhesive powder
Baking the powder to melted state
Heating and press for 8-15 sec
Peeling off the sheet
Print image transfer on the product
| Model | DTF-3020 |
| Printhead | Epson XP600 |
| Maximum Print Size | 300mm |
| Maximum Print Thickness | 0-2mm |
| Printing Material | Heat Transfer PET Film |
| Printing Quality | True Photographic Quality |
| Ink Colors | CMYK+WWWW |
| Ink Type | DTF Pigment ink |
| Ink System | CISS Built Inside With Ink Bottle |
| Printing Speed | 4 Pass: 8*㎡/hr 6 Pass: 6*㎡/hr 8 Pass: 4*㎡/hr |
| Servo Motor | Leadshine motor |
| Media Type | PP/PET/PP synthesized paper/ PET Film |
| File Format | PDF,JPG,TIFF,EPS,Postscript,etc |
| Operating System | WINDOWS 10/ WINDOWS 11 |
| Interface | 3.0 LAN |
| Software | Maintop/ Photoprint (optional) |
| Voltage | AC 220 V/110V 50HZ/60HZ |
| Power | 500W |
| Working Environment | 20 ~30Degrees |
| Package Type | Wooden Case |
| Machine Size | 960*650*440mm |
| Packing Size | 1040*650*600mm |
| Machine Weight | 60KG |
| Package Weight | 80KG |
| POWDER SHAKING MACHINE | |
| Max Media Width | 300mm |
| Voltage | 220V |
| Power | 1200W |
| Heating & Drying System | Front heat plate, dry fixation, cold fans function |
| Shaking Machine Size, Weight | 980*960*830mm 50Kg |
| Package Size, Weight | 870*860*760mm 58Kg |
✅ Installation & Setup Support
Our trained technicians will assist you with onsite installation and training for smooth operations.
✅ Remote Troubleshooting
Dedicated customer support via phone, video call, and remote desktop sessions for quick resolution.
✅ Spare Parts & Consumables
Ready availability of original spare parts, printheads, and UV inks to ensure uninterrupted operations.
✅ Annual Maintenance Contracts (AMC)
Optional AMCs are available to keep your machine running at peak performance with regular checkups.
Q1. What types of materials can be printed on?
A: You can print on various rigid materials like glass, ceramic, wood, MDF, acrylic, metal, PVC, sunboard, and more.
Q2. Does it support white and varnish printing?
A: Yes, the printer supports CMYK+W (White) and CMYK+WV (White + Varnish) configurations.
Q3. What is the maintenance requirement?
A: Regular head cleaning and system checkups are recommended. We provide detailed guidance and support.
Q4. Can I print on dark surfaces?
A: Absolutely! With white ink support, you can easily print on dark or colored surfaces.
Q5. Is training provided?
A: Yes, complete training is provided during installation including software usage and media handling.
Q6. What is the lifespan of the printhead?
A: With proper maintenance,Printheads last for a long time.
Q7. What is the drying time for the prints?
A: The UV lamps provide instant drying, enabling immediate handling or post-processing.
