Laser Cutting Machine

Laser Engraver/Cutting Machine

Core Details

Drive system with high precision speed guide with roller high precision, wear resistance, small resistance, high speed, arc gear synchronous belt.
Equipped with manual modulation focused laser head, responsive and accurate, the machine can adjust the focused position according to engraving and cutting alternation.
Lastest technology stepper motor and servo drive system technology

Applicable Industries

Signage
Indoor and outdoor advertisement, Art & craft, Gift, Toys, Model cutting
Interior and Decorators, Paper & Packaging
Wood and MDF Cutting

Model No	1325	1390	1212	9060	1601
Laser Type	CO2 DC glass lasertube/ RF Metal Tube (optional)
Laser Power	60/80/100/130/150 Watt
Wave Length	10.6um
Re-positioning Accuracy	0.1mm
Cutting Speed	0-30000 mm/min
Engraving Speed	0-64000 mm/min
Cooling Method	Water cooled
Water Environment	Temperature:0-45,Humidity 5-95%(No Condensate Water)
Acceleration Speed	1G
Working Area (in mm)	1300X2500	1300X900	1200X1200	900X600	1600X1000
Graphic File Support	.PLT,.CDR,.AI,.DWG,.DFX,.DST,.BMP,.JPEG,.TIFF,.GIF,.PCX etc
Laser Output Control	0-100% set by software
Min. Engraving Size	English Letter 2mm X 2mm
Highest Scanning Precision	4000DPI
Locating Accuracy	<±0.01mm
Controlling Software	DSP Control System
Compatible Software	CORELDRAW,PHOTOSHOP,AUTOCAD
Colour Separation	Yes
Drive System	High-Precision 3-phase Stepper Motor
Auxiliary Equipment	Exhaust Fan and Air Exhaust Pipe
Power Supply	230V±10%,50HZ/60HZ

AFTER-SALES SERVICE

✅ Installation & Setup Support
Our trained technicians will assist you with onsite installation and training for smooth operations.

✅ Remote Troubleshooting
Dedicated customer support via phone, video call, and remote desktop sessions for quick resolution.

✅ Spare Parts & Consumables
Ready availability of original spare parts, printheads, and UV inks to ensure uninterrupted operations.

✅ Annual Maintenance Contracts (AMC)
Optional AMCs are available to keep your machine running at peak performance with regular checkups.

FREQUENTLY ASKED QUESTIONS (FAQ)

Q1. What types of materials can be printed on?
A: You can print on various rigid materials like glass, ceramic, wood, MDF, acrylic, metal, PVC, sunboard, and more.

Q2. Does it support white and varnish printing?
A: Yes, the printer supports CMYK+W (White) and CMYK+WV (White + Varnish) configurations.

Q3. What is the maintenance requirement?
A: Regular head cleaning and system checkups are recommended. We provide detailed guidance and support.

Q4. Can I print on dark surfaces?
A: Absolutely! With white ink support, you can easily print on dark or colored surfaces.

Q5. Is training provided?
A: Yes, complete training is provided during installation including software usage and media handling.

Q6. What is the lifespan of the printhead?
A: With proper maintenance,Printheads last for a long time.

Q7. What is the drying time for the prints?
A: The UV lamps provide instant drying, enabling immediate handling or post-processing.
