Intelligent Print Head Control System
Ease of operations
Adjustable Printhead Height
Controlling Ink Wastage
Ink Curing System
Photoprint Rip Software with ICC profiling enabled
Print Head Protection
Dual Guide Rail
Multilayer/Spot White/Varnish Printing
Stable Air Pressure Ink Supply
Auto Head Clean
Double Anti Static Bar
Individual Sub Tank Heater
7 Colour Optional and 3d Printing
Ink Reserve Alarm
International Design and Machine Frame
| Model | Q2 Hybrid |
| Printing Heads | KM 1024i / Ricoh Gen5 / Kyocera |
| Printhead Quantity | 16 (Max.) – 8 (Max.) – 6 (Max.) |
| Drop Volume | 16 Pl. – 13 Pl. – 7 Pl. – 3 Pl. |
| Color Scale | CMYK + White + Varnish + Lc + Lm |
| Ink Type | UV – LED |
| Drying System | UV Curing – LED Curing |
| Print Width | 2050 mm |
| Print Height | 50 mm |
| Print Resolution | 2880 dpi – 1200 dpi – 2400 dpi |
| Printing Speed Upto | 90* m²/h |
| RIP Software | Photo Print – Caldera (Opt.) |
| Hardware | LCD Monitor |
| Power Requirement | 230v (+/-) 10% / 40A / 50HZ / 60HZ |
| Machine Weight | 2000 kg |
✅ Installation & Setup Support
Our trained technicians will assist you with onsite installation and training for smooth operations.
✅ Remote Troubleshooting
Dedicated customer support via phone, video call, and remote desktop sessions for quick resolution.
✅ Spare Parts & Consumables
Ready availability of original spare parts, printheads, and UV inks to ensure uninterrupted operations.
✅ Annual Maintenance Contracts (AMC)
Optional AMCs are available to keep your machine running at peak performance with regular checkups.
Q1. What types of materials can be printed on?
A: You can print on various rigid materials like glass, ceramic, wood, MDF, acrylic, metal, PVC, sunboard, and more.
Q2. Does it support white and varnish printing?
A: Yes, the printer supports CMYK+W (White) and CMYK+WV (White + Varnish) configurations.
Q3. What is the maintenance requirement?
A: Regular head cleaning and system checkups are recommended. We provide detailed guidance and support.
Q4. Can I print on dark surfaces?
A: Absolutely! With white ink support, you can easily print on dark or colored surfaces.
Q5. Is training provided?
A: Yes, complete training is provided during installation including software usage and media handling.
Q6. What is the lifespan of the printhead?
A: With proper maintenance,Printheads last for a long time.
Q7. What is the drying time for the prints?
A: The UV lamps provide instant drying, enabling immediate handling or post-processing.
