UV Platinum KC Plus 3020

       Advantages

  • Auto Height Detection – Print head Height detection is Automatic. Color Profiles – We do create ICC Profile according to print media

  • Motor Drive – We use High Quality Motor drive for Longer Life of the machine

  • White Ink Circulation – For Smoother print of White Color Proper Circulation & Degassing for white ink is installed

  • Auto Ink Alarm – Ink reserve Alarm always to inform you which color is short

  • Spot White Print – Our Machine Software Includes option for Spot Printing of white & Varnish

  • Print Head Protection – Print Heads are well protect with Anti Crash System

  • Color Profiles – We do create ICC Profile according to print media which saves you a lot of ink and provides you actual color all tim

ModelPlatinum UV 2512                          Platinum UV 3020
Max. Printing Size2500mm x 1250mm                          3050mm x 2050mm
Printhead Tech.Drop on demand micro piezo-electric digital inkjet Printer
PrintheadKm1024i / RicohGen5 / RicohGen6
Print Resolution 720 x 1440dpi(Max)
Print Head No433
Print Speed (Express Mode)60*m²/hr20*m²/hr30*m²/hr
Print Speed (Standard Mode)40*m²/hr17*m²/hr25*m²/hr
Print Speed (Quality Mode)22*m²/hr10*m²/hr17*m²/hr
Optional color ConfigurationCMYK W, CMYK LcLm, CMYK LcLm W,CMYK CMYK ,CMYK W V ,CMYK LC LM W V
Max. Media Thickness0-100mm
Ink Supply SystemNegative Pressure Auto ink Supply
Drying SystemUV Lamps Instant Drying
Media AbsorptionVaccum Enabled
Table Pressure35kg/m2
Printable MediaGlass, Ceramic, PVC, Wood, Metal, Sunboard, Sunpack, Acrylic, MDF, Doors & All Rigid Materials etc.
InterfaceUSB 2.0
RIP SoftwarePhotoprint Dx19 / Caldera (optional)
PowerAC 220V, 50/60 Hz
Operational EnvironmentTemperature: 18°C ~ 22°C, Humidity 35% RH ~ 65% RH
Dimensions    5210 x 2102 x 1530 (mm)                 5760 x 2910 x 1530 (mm)
AFTER-SALES SERVICE

Installation & Setup Support
Our trained technicians will assist you with onsite installation and training for smooth operations.

Remote Troubleshooting
Dedicated customer support via phone, video call, and remote desktop sessions for quick resolution.

Spare Parts & Consumables
Ready availability of original spare parts, printheads, and UV inks to ensure uninterrupted operations.

Annual Maintenance Contracts (AMC)
Optional AMCs are available to keep your machine running at peak performance with regular checkups.


FREQUENTLY ASKED QUESTIONS (FAQ)

Q1. What types of materials can be printed on?
A: You can print on various rigid materials like glass, ceramic, wood, MDF, acrylic, metal, PVC, sunboard, and more.

Q2. Does it support white and varnish printing?
A: Yes, the printer supports CMYK+W (White) and CMYK+WV (White + Varnish) configurations.

Q3. What is the maintenance requirement?
A: Regular head cleaning and system checkups are recommended. We provide detailed guidance and support.

Q4. Can I print on dark surfaces?
A: Absolutely! With white ink support, you can easily print on dark or colored surfaces.

Q5. Is training provided?
A: Yes, complete training is provided during installation including software usage and media handling.

Q6. What is the lifespan of the printhead?
A: With proper maintenance,Printheads last for a long time.

Q7. What is the drying time for the prints?
A: The UV lamps provide instant drying, enabling immediate handling or post-processing.
