Platinum UV Roll to Roll

     Key Features

  • Extremely wide media and applications scope
    Wide Range media use

  • Free fall option reduces media waste – Pinch rollers on bed enable free fall printing. This comes in handy to print on demand and results in optimal media use.

  • Convenient media loading – The Platinum was designed with a view to offering convenience, lean operations and peace of mind.

  • Immediate quality inspection – A light box next to the printing area allows for on-the-spot quality inspection of backlit prints.

  • Vivid prints, low ink consumption

ModelPLATINUM UV RL-3200
Printhead Tech.Drop on demand micro piezo-electric digital inkjet Printer
PrintheadKM-1024i-13PL / KM1024i-6PL / RICHOGEN5 (OPTIONAL)
Printhead Quantity4-14 (Optional)
Print Resolution2880dpi(Max)
Ink ColorC M Y K + Lc Lm W (Lc Lm W are Optional)
Ink TypeUV INK
Drying SystemUV LED-Curing
Media Print Width3.20m / 126in
Media TypePaper, Vinyl, Canvas, One way Vision, Banner, Textile, Backlits, PP, Wallpaper, Softmedia etc.
Print Speed up to120* m2/hr
Media TransmissionPre Heater, Dancer Bars and Print Plate Suction for Roll to Roll & Free Fall
InterfacePCI Express
RipsoftwarePhotoprint Dx19 / Caldera (Optional)
PowerAC 220V , 50/60 Hz
Operational EnvironmentTemprature : 18°C ~ 22°C, Humidity 35% RH ~ 65% RH
G.Weight1450kg
AFTER-SALES SERVICE

Installation & Setup Support
Our trained technicians will assist you with onsite installation and training for smooth operations.

Remote Troubleshooting
Dedicated customer support via phone, video call, and remote desktop sessions for quick resolution.

Spare Parts & Consumables
Ready availability of original spare parts, printheads, and UV inks to ensure uninterrupted operations.

Annual Maintenance Contracts (AMC)
Optional AMCs are available to keep your machine running at peak performance with regular checkups.


FREQUENTLY ASKED QUESTIONS (FAQ)

Q1. What types of materials can be printed on?
A: You can print on various rigid materials like glass, ceramic, wood, MDF, acrylic, metal, PVC, sunboard, and more.

Q2. Does it support white and varnish printing?
A: Yes, the printer supports CMYK+W (White) and CMYK+WV (White + Varnish) configurations.

Q3. What is the maintenance requirement?
A: Regular head cleaning and system checkups are recommended. We provide detailed guidance and support.

Q4. Can I print on dark surfaces?
A: Absolutely! With white ink support, you can easily print on dark or colored surfaces.

Q5. Is training provided?
A: Yes, complete training is provided during installation including software usage and media handling.

Q6. What is the lifespan of the printhead?
A: With proper maintenance,Printheads last for a long time.

Q7. What is the drying time for the prints?
A: The UV lamps provide instant drying, enabling immediate handling or post-processing.
