F-1810 UV Flatbed Printer

New, large, and uniquely designed dimensions make it exclusive, economical, and high-performing.
Latest and larger bed print area ensures better print quality and improved productivity.
Highly demanded product in the current market.
A favorite among small and medium businesses for its efficiency and value.
Equipped with the most stable Negative Pressure Ink Supply System for uninterrupted performance.
Automated Ink Circulation System prevents pigment settling in ink lines, ensuring consistent output.

Model	F-1810
Printhead Tech.	Drop on demand micro piezo-electric digital inkjet Printer
Head Type	Epson i3200 / Ricoh Gen5i / Ricoh Gen5 (optional)
Head Quantity	2-3 pcs (optional)
Media Thickness	0-85mm
Print Size	1800*1000mm
Ink Color	CMYK+CMYK/CMYK+W/CMYK+W+V/CMYKCMYK+W
RIP Software	PhotoPrint
Printer Software	Printer Express
Printer Speed	Sketch Mode: 720600dpi-9sqm/h Production Mode: 720900dpi-8sqm/h High Quality Mode: 7201200dpi-6.5sqm/h
Ink Supply Mode	Constant Pressure (Negative Pressure System)
Media Type	Wood panel, Aluminium panel, Glass, Ceramics, Acrylic, PVC, MDF etc.
Maximum Weight of Material	Panel: ≤ 45 kg/m2
Data Interface	Hi-Speed USB 2.0
Curing Mode	UV-LED Cold Light Source (with water chiller)
Image Format	TIFF/JPEG/AI/PDF/PSD etc
Computer System	Windows 10-64 Bit/ Windows 11-64 Bit
Maximum Power	>30A; 5KW
Machine Dimension	2610mm x 2380mm x 1500mm
Package Dimension	2860mm x 2460mm x 1680mm
Environment Requires	Dust-free environment with no direct sunlight and good ventilation. The optimal temperature is 18-22°C and the relative humidity is 30-70%

AFTER-SALES SERVICE

✅ Installation & Setup Support
Our trained technicians will assist you with onsite installation and training for smooth operations.

✅ Remote Troubleshooting
Dedicated customer support via phone, video call, and remote desktop sessions for quick resolution.

✅ Spare Parts & Consumables
Ready availability of original spare parts, printheads, and UV inks to ensure uninterrupted operations.

✅ Annual Maintenance Contracts (AMC)
Optional AMCs are available to keep your machine running at peak performance with regular checkups.

FREQUENTLY ASKED QUESTIONS (FAQ)

Q1. What types of materials can be printed on?
A: You can print on various rigid materials like glass, ceramic, wood, MDF, acrylic, metal, PVC, sunboard, and more.

Q2. Does it support white and varnish printing?
A: Yes, the printer supports CMYK+W (White) and CMYK+WV (White + Varnish) configurations.

Q3. What is the maintenance requirement?
A: Regular head cleaning and system checkups are recommended. We provide detailed guidance and support.

Q4. Can I print on dark surfaces?
A: Absolutely! With white ink support, you can easily print on dark or colored surfaces.

Q5. Is training provided?
A: Yes, complete training is provided during installation including software usage and media handling.

Q6. What is the lifespan of the printhead?
A: With proper maintenance,Printheads last for a long time.

Q7. What is the drying time for the prints?
A: The UV lamps provide instant drying, enabling immediate handling or post-processing.
