Small size UV flatbed printer (600 mm x 900 mm) perfect for a startup business
Multifunctional UV printing machine for flatbed and cylindrical objects
High-precision Epson printhead to ensure unbeatable image quality
Low maintenance cost
Cost-effective, stable performance
Wide range of applications
User-friendly operating system
| Model | F-6090 |
| Head Type | Epson i3200 / Ricoh Gen5i (optional) |
| Printing Board | Hoson |
| Max Print Size | 60cm x 90cm |
| Max Print Height | 200mm |
| Materials to Print | Rotary, Metal, Plastic, Glass, Wood, Ceramics, Acrylic, Leather, etc |
| Ink Colors | CMYK+W+V |
| Ink Type | UV Ink |
| Ink Supply System | Negative Pressure Auto Ink Supply |
| UV Lamp | 2 pcs Air Cooling Lamp, 70w Control White and Color, 35w Control Varnish |
| UV Lamp Cooling Method | Water Cooling |
| White Ink Circulation System | Equipped |
| Automatic Height Detection | Equipped |
| Print Head Anti-collision System | Equipped |
| Color Control | International ICC Profile, the Profile and Density can be adjusted |
| File Format | PDF, JPG, TIFF, EPS, AI, etc |
| Max Media Weight | 30 KG |
| Operating System | WINDOWS 10 / WINDOWS 11 |
| Interface | 3.0 LAN |
| Software | Ripprint / Photo Print |
| Voltage | 110V / 220V |
| Power Consumption | 700w |
| Machine Size & Net Weight | 1570mm * 1400mm * 650mm, 140kg |
| Package Size & Gross Weight | 1670mm * 1500mm * 830mm, 230kg |
✅ Installation & Setup Support
Our trained technicians will assist you with onsite installation and training for smooth operations.
✅ Remote Troubleshooting
Dedicated customer support via phone, video call, and remote desktop sessions for quick resolution.
✅ Spare Parts & Consumables
Ready availability of original spare parts, printheads, and UV inks to ensure uninterrupted operations.
✅ Annual Maintenance Contracts (AMC)
Optional AMCs are available to keep your machine running at peak performance with regular checkups.
Q1. What types of materials can be printed on?
A: You can print on various rigid materials like glass, ceramic, wood, MDF, acrylic, metal, PVC, sunboard, and more.
Q2. Does it support white and varnish printing?
A: Yes, the printer supports CMYK+W (White) and CMYK+WV (White + Varnish) configurations.
Q3. What is the maintenance requirement?
A: Regular head cleaning and system checkups are recommended. We provide detailed guidance and support.
Q4. Can I print on dark surfaces?
A: Absolutely! With white ink support, you can easily print on dark or colored surfaces.
Q5. Is training provided?
A: Yes, complete training is provided during installation including software usage and media handling.
Q6. What is the lifespan of the printhead?
A: With proper maintenance,Printheads last for a long time.
Q7. What is the drying time for the prints?
A: The UV lamps provide instant drying, enabling immediate handling or post-processing.
Print stylish, durable designs directly on custom mobile cover surfaces.
Print vibrant, durable designs directly on sleek aluminium surfaces.
Create sharp, high-quality visuals on glass for décor or partitions.
Print attractive, high-quality designs directly on durable book covers.
